USB3.0 Interface enables higher performanceXI006AUSB adopts USB 3.0 interface and realizes high-speed transmission. It can simultaneously capture 6 CVBS and 6 unbalanced stereo audio. It gets power from PC directly and has no need of extra power adapter, which enables to be carried easily. Compared to PCI-Express x1 GEN 1.1 interface, the Intel USB 3.0 chip enables a nearly 50% faster data transmission at 1080p60. XI100XUSB-PRO is compatible with USB 2.0 or you can get an extended USB 3.0 by a PCI Express card.
The best capture of analog signalsIt can simultaneously capture 6-channel CVBS and 6-channel unbalanced stereo audio with each channel at D1/30 fps. It does not have the phenomenon of losing frames or video tearing and is compatible with PAL and NTSC standards. It can automatically detect the video standards of input signals without manual settings.
High-quality Experience of Audio and VideoIt adopts technologies of AD converter, with the sampling precision rate at 10 bits, and 5-tap motion-adaptive comb filter to ensure the sharpness of images and the minimum image noises. The image details will be more colorful and reduce the color edges; it adopts A/D converter with the sample rate at 96KHz and 24 bits sampling precision rate, and the SNR in actual experiences is about 90 db. The high sampling rate and high sampling precision can ensure the minimum distortion of sampling, and the high SNR can ensure pure voice.
Image Scale and ClippingXI006AE-PRO can scale or clip input signals by accessory AMCAP tool to satisfy your individual requirements and bring more personalized experience.
Streaming Media Live BroadcastThe compressed video, if it is compressed into stream media format, will lower its quality and will consume more CPU. The pure uncompressed video source will improve the quality of internet stream media video. It supports leading stream media software and does not need secondary development. It enables to capture the video in its best quality and then compress it into any specific formats which are fit for internet publication, and users can establish their own IPTV!
Compatibility with more softwareIt adopts standard development interface and is based on audio and video capture interface of DirectShow Filter and audio capture interface of DirectSound. It is based on IKsPropertySet expansion interface and it's compatible with more software, like Windows Media Encoder, Adobe Flash Media Live Encoder, Real Producer Plus, VideoLAN for Windows.
Flexible Multi-channel CaptureIt has the feature of SimuStream, and multiple applications can simultaneously run and capture while the frame rate stays unchanged. It is allowed that different applications use different capture formats. One video source can be dealt into multiple formats or bit rates or resolutions. It will help reduce cost for users' whole solution.
High-quality Components Enable a super stable performanceAll the chips and capacity cells are imported components of high quality. It adopts the design of 8 layers. The signal performance is better than similar products, which can work at its full capacity for super long hours, i.e. continuously work 24hx7 without stopping.
Easy Hardware UpdateIt adopts Magewell exclusive video processing engines, and it is highly flexible. You update Magewell processing engines by firmware and driver update without replacing the hardware. It can achieve the result of hardware update even if the chips remain unchanged. It largely reduces the cost of maintenance and succeeds in providing perfect service.
