Camera Preset Positioning
Extremely fast and smooth movement
Seven presets on handheld remote or using our exclusive desktop control
RS-232 Control Serial connection for external control systems
Preset positioning, up to 255 separate locations!
UVC Over USB Control Enables far end camera control when available in your software codec
PC desktop control program (download for free from our website)
Dual IR receivers One in base and one in the lens assembly for a wide range of control positions
IR Controls include a “Video Mute†and power on/off
Accu Pan And Tilt Slow movement when needed for fine tuning of camera position
Rapid motion when you move a wide range
Extreme Performance Camera Block 10x optical zoom
Wide angle lens with low light capability
Low light capability
Wide dynamic range for true-to-life color rendition
Belt Drive For Ultra Smooth Pan And Tilt Ultra quiet motion with no “jerkinessâ€Â
Attractive Form Factor Compact in size for discrete placement in the most discerning environments
Metal frame for a medern look
SPECIFICATIONS 10x optical zoom
Focus range/depth of field: f4.7 – 47mm/58cm-infinity
Optical distortion: -1.12% -+0.65%
Dynamic range: 100db
SNR: 50db above
FOV: Horizontal 62.5-6.43
Sensor size: CMOS 1/2.8″
Standard center tripod mount: 1/4″/20 thread
MJPEG format with resolution at 640×480, 1280×720, and 1920×1080, all at 30fps
USB 2.0 output
Dual IR receivers, one on front of base, one on front of lens housing
Belt drive low-noise stepper motors with variable speed
12V DC input at 2A
W 4 5/8″ (117.5mm), D 4 1/2″ (112.7mm), H 5 5/8″ (143.2mm)
Weight: 1lb 11oz (.77Kg)
Fast, professional autofocus
WHAT'S IN THE BOX CompassX PTZ Camera
Full function IR remote and batteries
Combination mounting solution for monitor or wall
USB cable
RS-232 cable
AC adapter power supply
